Peoplevox + Le New Black integration overview
Peoplevox is a warehouse management system (WMS) that provides online inventory management. Le New Black offers a collaborative B2B portal for your team and retailers, and an order-taking iPad app for your sales team.
The connector uses the Peoplevox API to exchange data (read docs) |
|
Le New Black drives all data flows: it triggers every push and pull operation |
|
The connector requires basic configuration in Le New Black and Peoplevox |
Data flows
| Type | Flow |
| Inventory stock levels | Peoplevox ⇢ Le New Black |
| Orders | Peoplevox ⇠ Le New Black |
Data flow: Inventory stock levels
Peoplevox sends the available stock of each item type.
Reference
Trigger: Scheduled task, active once Le New Black has set up the flow for your brand. It can also be run on demand from the Integration center.
Limit: Up to 9,500 item types per run, read 500 at a time
Quantity imported: The Peoplevox available stock of each item code
Matching keys: Size: EAN13, or SKU when set up, matched against the Peoplevox item code.
Import mode: Add by default → only the sizes in the Peoplevox data are updated, the others keep their quantity. Replace, when set up → the stock of every size is set to 0 before the quantities are applied. Negative quantities are imported as 0.
Rejected rows: A Peoplevox item code unknown in Le New Black is ignored and reported in the task log: import products first.
Configuration
| Setting | Values | Type | Comment |
import_mode |
add (default) / replace | string | With replace, the stock of every size is set to 0 before the quantities are applied |
lnb_sku_identifier_column |
ean13 (default) / sku | string | Le New Black key the stock rows are matched against |
lnb_stock_column |
quantity (default) / incoming_quantity | string | Le New Black quantity updated |
Data flow: Orders
Orders you move to the exported status (Invoicing by default) are created in Peoplevox as sales orders, for the warehouse site set up for your brand.
Reference
Trigger: Scheduled task, active once Le New Black has set up the flow for your brand. It can also be run on demand from the Integration center.
Orders exported: Status Invoicing
Integration status: Only orders whose integration status is Pending are exported, and it becomes Successfully sent after export. The selection can be adapted during set-up.
Status after export: Closed
Blocked orders: An order that fails a check keeps its status and gets the integration status Blocked, with the reason in the task log. It is not sent again until you set its integration status back to Pending from the orders list (action Set integration status to Pending).
Limit: No limit
Sales order: A Peoplevox sales order numbered "PO-" followed by the Le New Black order number, for the warehouse site of the configuration, requested for delivery at the export date, and one sales order item per ordered size with its item code and quantity
Matching keys: Products: LNB SKU, sent as the Peoplevox item code.
Not synchronised: The customer, the addresses, the prices and the delivery dates of the order are not part of the sales order sent.
Configuration
| Setting | Values | Type | Comment |
warehouse_site_ref |
Peoplevox site reference | string | Peoplevox warehouse site the sales orders are created for |
validate_stock_ats |
true / false | bool | With true, the orders are exported in stock allocation order: by status (Invoicing first), then by date |
Callouts
- An order containing a product without a SKU is blocked as a whole: none of its lines is exported.
- An order without any line is blocked.
- After the order has been exported from Le New Black, any further change must be made directly in Peoplevox.
Global configuration
Configuration
| Setting | Values | Type | Comment |
account |
Peoplevox account | string | Credential of your Peoplevox account, set up with your account manager |
client_id |
Peoplevox client id | string | Credential of your Peoplevox account, set up with your account manager |
login |
Peoplevox user name | string | Credential of your Peoplevox account, set up with your account manager |
password |
Peoplevox user credential | string | Credential of your Peoplevox account, set up with your account manager |
Integration project
Who's assigned from your team?
Your Peoplevox administrator, or an IT profile within your company who is familiar with your specific setup. A Sales Manager who understands your business and your merchandising strategy.
Who's in charge at Le New Black
Your account manager at Le New Black takes care of the whole process from day 1:
- Asking questions about your specific Peoplevox setup and sales process.
- Setting up the connection with your Peoplevox account.
- Generating and exporting test orders to Peoplevox.
- Keeping your team updated throughout the process and addressing delays on either side.
- Working with you and Peoplevox to troubleshoot any unexpected issue after launch.
Timeline
A standard integration of the inventory stock levels and orders data flows will take 2-4 weeks to get up and running.
Integration monitoring
Once the connector is set up, the Integration center of your back-office gives you a set of tools to manage and monitor the integration:
- Task logs, for continuous monitoring and troubleshooting (for example a missing EAN13 or retailer reference that prevents an order from being exported)
- Running a task on demand, to push or pull data at once
- A preview of the data before the actual import (only available on some connectors)
- E-mail notifications per task, set up on request: exported and blocked orders, import errors
- The integration status of each order in the orders list (Pending, Successfully sent, Blocked), which you can set back to Pending to send an order again
